Apache Pinot Batch Import using HDFS

Overview

This document provides a step-by-step guide for batch importing data into Apache Pinot using HDFS as the storage backend.

Before running any Pinot commands, make sure to set Java 11 on the CLI and export other required configurations.

export JAVA_HOME=/usr/lib/jvm/java-11-openjdk-11.0.25.0.9-2.el8.x86_64
export PATH=$JAVA_HOME/bin:$PATH

export JAVA_OPTS="-Xms1G -Xmx2G"
export LOG_ROOT=/var/log/pinot

Create different tables and schemas.

Prepare the Data

Create a directory to store raw data.

mkdir -p /tmp/pinot-quick-start-new/rawdata

Create a sample CSV file with transcript data:

cat <<EOF > /tmp/pinot-quick-start-new/rawdata/transcript-hdfs.csv
transcriptID,firstName,lastName,gender,subject,score,timestampInEpoch
500,Lucy,Smith,Female,Maths,3.8,1570863600000
500,Lucy,Smith,Female,English,3.5,1571036400000
501,Bob,King,Male,Maths,3.2,1571900400000
502,Nick,Young,Male,Physics,3.6,1572418800000
EOF

Define Schema and Table Configuration

Schema Definition

cat <<EOF > /tmp/pinot-quick-start-new/transcript-hdfs-schema.json
{
  "schemaName": "transcripthdfs",
  "dimensionFieldSpecs": [
    {"name": "transcriptID", "dataType": "INT"},
    {"name": "firstName", "dataType": "STRING"},
    {"name": "lastName", "dataType": "STRING"},
    {"name": "gender", "dataType": "STRING"},
    {"name": "subject", "dataType": "STRING"}
  ],
  "metricFieldSpecs": [
    {"name": "score", "dataType": "FLOAT"}
  ],
  "dateTimeFieldSpecs": [{
    "name": "timestampInEpoch",
    "dataType": "LONG",
    "format" : "1:MILLISECONDS:EPOCH",
    "granularity": "1:MILLISECONDS"
  }]
}
EOF

Table Definition

cat <<EOF > /tmp/pinot-quick-start-new/transcript-hdfs-table-offline.json
{
  "tableName": "transcripthdfs",
  "tableType": "OFFLINE",
  "segmentsConfig": {
    "timeColumnName": "timestampInEpoch",
    "timeType": "MILLISECONDS",
    "replication": "1",
    "schemaName": "transcripthdfs"
  },
  "tableIndexConfig": {
    "invertedIndexColumns": [],
    "loadMode": "MMAP"
  },
  "tenants": {
    "broker": "DefaultTenant",
    "server": "DefaultTenant"
  },
  "metadata": {}
}
EOF

hdfs dfs -mkdir -p /tmp/pinot-quick-start-new/rawdata/
hdfs dfs -put transcript-hdfs.csv /tmp/pinot-quick-start-new/rawdata/
hdfs dfs -ls /tmp/pinot-quick-start-new/rawdata/

Upload Schema and Table Configuration

curl -X POST "http://{hostname}or{IP}:9000/schemas" -H "Content-Type: application/json" -d @/tmp/pinot-quick-start-new/transcript-hdfs-schema.json

curl -X POST "http://{hostname}or{IP}:9000/tables" -H "Content-Type: application/json" -d @/tmp/pinot-quick-start-new/transcript-hdfs-table-offline.json

Configure Batch Ingestion Job

Configuration in case of Kerberos Enabled Cluster

In case you are using Kerberos, add the below properties.

In Advanced pinot-controller-conf, add the below properties, save, and restart the Pinot Service from Ambari.

pinot.controller.storage.factory.class.hdfs=org.apache.pinot.plugin.filesystem.HadoopPinotFS
pinot.controller.storage.factory.hdfs.hadoop.conf.path=file:///etc/hadoop/conf
pinot.controller.segment.fetcher.protocols=file,http,hdfs
pinot.controller.segment.fetcher.hdfs.class=org.apache.pinot.common.utils.fetcher.PinotFSSegmentFetcher
pinot.controller.segment.fetcher.hdfs.hadoop.kerberos.principle=hdfs-pinottest@ADSRE.COM
pinot.controller.segment.fetcher.hdfs.hadoop.kerberos.keytab=/etc/security/keytabs/hdfs.headless.keytab

Preserved image

Info

Remove the following properties in case you are not using Kerberos from the below yaml file and above mentioned Kerberos configurations from the Pinot Controller conf.

hadoop.kerberos.principle: "hdfs-pinottest@ADSRE.COM"
hadoop.kerberos.keytab: "/etc/security/keytabs/hdfs.headless.keytab"
hadoop.security.authentication: "kerberos"

Create a batch ingestion job configuration file:

cat <<EOF > batch-job-spec-hdfs.yml
executionFrameworkSpec:
  name: "standalone"
  segmentGenerationJobRunnerClassName: "org.apache.pinot.plugin.ingestion.batch.standalone.SegmentGenerationJobRunner"
  segmentTarPushJobRunnerClassName: 'org.apache.pinot.plugin.ingestion.batch.standalone.SegmentTarPushJobRunner'
  segmentUriPushJobRunnerClassName: 'org.apache.pinot.plugin.ingestion.batch.standalone.SegmentUriPushJobRunner'
  segmentMetadataPushJobRunnerClassName: 'org.apache.pinot.plugin.ingestion.batch.standalone.SegmentMetadataPushJobRunner'
  extraConfigs:
      stagingDir: 'hdfs://{hostname}or{IP}:8020/tmp/pinot/output/transcripthdfsnew'

jobType: 'SegmentCreationAndTarPush'
pushJobSpec:
        pushFileNamePattern: 'glob:**\/*.tar.gz'
inputDirURI: 'hdfs://{hostname}or{IP}:8020/tmp/pinot-hadoop/rawdata/'
includeFileNamePattern: 'glob:**/*.csv'
outputDirURI: 'hdfs://{hostname}or{IP}:8020/tmp/pinot-hadoop/segments/'
overwriteOutput: true

pinotFSSpecs:
  - scheme: "hdfs"
    className: "org.apache.pinot.plugin.filesystem.HadoopPinotFS"
    configs:
            hadoop.conf.path: "/etc/hadoop/conf"
            hadoop.kerberos.principle: "hdfs-pinottest@ADSRE.COM"
            hadoop.kerberos.keytab: "/etc/security/keytabs/hdfs.headless.keytab"
            hadoop.security.authentication: "kerberos"


recordReaderSpec:
  dataFormat: 'csv'
  className: 'org.apache.pinot.plugin.inputformat.csv.CSVRecordReader'
  configClassName: 'org.apache.pinot.plugin.inputformat.csv.CSVRecordReaderConfig'
tableSpec:
  tableName: 'transcripthdfsnew'
  schemaURI: 'http://{hostname}or{IP}:9000/tables/transcripthdfsnew/schema'
  tableConfigURI: 'http://{hostname}or{IP}:9000/tables/transcripthdfsnew'
pinotClusterSpecs:
  - controllerURI: 'http://{hostname}or{IP}:9000'
EOF

Set Up Hadoop Environment Variables

export HADOOP_HOME=/usr/odp/3.3.6.3-1/hadoop/
export HADOOP_CONF_DIR=$HADOOP_HOME/etc/hadoop
export PATH=$HADOOP_HOME/bin:$PATH

Run the Batch Ingestion Job

Execute the following command to launch the data ingestion job:

JAVA_OPTS="-Xms512m -Xmx1g" bin/pinot-admin.sh LaunchDataIngestionJob -jobSpecFile batch-job-spec-hdfs.yml
