Configure Pulse to Monitor Standalone Kafka 3

Questions asked by CLI

Guidelines for answering the questions

Select the cluster type

Select the cluster type as Standalone. [x] Stand-Alone [ ] Ambari [ ] Cloudera

Select the Kafka 3 Standalone component.

[ ] Kafka

[ ] NiFi

[ ] Spark

[x] Kafka 3

If your Kafka 3 deployment uses KRaft mode, select Kafka 3.

If your Kafka 3 deployment uses ZooKeeper mode, select Kafka.

Based on your environment, select the appropriate component and enter the required details.

In this document, the scenario assumes a Kafka 3 deployment with KRaft mode. However, the remaining steps are the same for both modes.

Enter Your Cluster's Display Name

Enter the cluster name.

Enter Kafka 3 Version

Enter the Kafka 3 version.

Enter one of the Kafka bootstrap server's URIs (e.g., host1.kf.com:6667):

Enter one of the Kafka 3 bootstrap server URIs

Select the detected Kafka 3 brokers after Pulse auto-detects them.

✓ Detected kafka3 brokers: kafka101.acceldata.dvl:9092 kafka102.acceldata.dvl:9092 kafka103.acceldata.dvl:9092 ✓ Total number of brokers: 3

Select the security type used by your Kafka cluster.

On Pulse 4.0.3 or earlier:

None

Plain/SASL

Scram

Based on the selection of each security type, the CLI prompts with a set of questions to enter the details.

Enter the Kraft Controller URLs (comma separated with host & port, e.g., krafthost1:19092,krafthost2:19092)

Enter the Kraft Controller URLs (e.g., krafthost1:19092,krafthost2:19092).

Do you want to monitor KafkaMM2 [y/n]

Enter the Kafka MirrorMaker nodes (comma-separated hosts, e.g., mm2kafka1,mm2kafka2)

Type y if you want to monitor Kafka Mirror Maker 2 and enter the host names.

Do you want to monitor Kafka Connect [y/n]

Enter the Kafka Connect nodes (comma-separated hosts, e.g., kafkaconnect1,kafkaconnect2):

Type y if you want to monitor Kafka Connect and enter the host names.

Do you want to monitor Kafka Cruise Control [y/n]

Enter the Kafka Cruise Control nodes (comma-separated hosts, e.g., kafkaconnect1,kafkaconnect2)

Type y if you want to monitor Kafka Cruise Control and enter the host names.

Do you want to monitor Schema Registry [y/n]

Enter the Schema Registry nodes (comma-separated hosts, e.g., schemaregistry1,schemaregistry2)

Type y if you want to monitor the Schema Registry and enter the host names.

Add JMX ports for data collection

Enter the Kafka3 Broker Port: : 9092

Enter the Kafka JMX Port (Ex, 9999): 9999

Enter the Kafka3 MirrorMaker JMX Port (Ex, 9998): 9998

Enter the Cruise Control3 JMX Port (default: 56667): 56667

Enter the Kafka3 Connect JMX Port (default: 9994): 9994

Enter the Schema Registry JMX Port (default: 8996)::8996

Select logs for installed/enabled components.

Select the logs for components that are installed/enabled in your target cluster:

[ x ] kraftbroker_err

[ x ] kafka3_connect_err, kern

[ x ] kafka3_controller

[ x ] kafka3_connect

[ x ] kafka3_cruise_control

[ x ] registry_err

[ x ] kafka3_log_cleaner

[ x ] kafka3_server

[ x ] kafka3_server_gc

[ x ] kraftcontroller_err

[ x ] syslog, registry_server

[ x ] kafka3_state_change

[ x ] kafka3_cruise_control_err
